50 Tons Tshwj Xeeb Hloov Tsheb Thauj Mus Los Ntawm-rail
Daim Ntawv Thov: Kev Lag Luam Hlau, Lub Hoobkas, Warehouse, Chaw nres nkoj
Hom Tshuaj: Zoo meej
Load peev: 1-300 Ton
Tshwj xeeb muaj nuj nqi: Anti-Explosion, Thaum tshav kub kub-Resistant, Lifting
Tswj hom: Pendant / Chaw taws teeb / PLC Tswj
Hwj chim hom: roj teeb / cable powered / rail powered....
Xim: Customzied
Trademark: PERFECT
Thauj Pob: Tag nrho lub laub yuav ntim los ntawm Tarp.
Specification: Customized
Xa kev nug
Product Details of50 Tons Tshwj Xeeb Hloov Tsheb Thauj Mus Los Ntawm-rail
tshwj xeeb hloov lub laub on-rail
Ib txoj kev txhim khu kev qha rau cov kab rov tav hloov ntawm cov loads raws txoj kev ruaj khov.
Cov tsheb thauj khoom yog ntsia rau ntawm txoj hlua steel rau kev thauj mus los raws txoj kev ruaj khov. Cov tsheb thauj khoom txheem yog DC powered. Raws li cov no yog cov tsheb thauj khoom semi-kev cai, lawv tuaj nyob rau hauv qhov ntev thiab dav ntawm kom haum rau daim ntawv thov. Muaj peev xwm muaj txog li 60 tonne
| Qauv | BXC-2T | BXC-10T | BXC-20T | BXC-30T | BXC-50T | BXC-63T | BXC-150T | |
| Rated load (T) | 2 | 10 | 20 | 30 | 50 | 63 | 150 | |
| Rooj loj | ntev (L) | 2000 | 3600 | 4000 | 4500 | 5500 | 5600 | 10000 |
| Dav (W) | 1500 | 2000 | 2200 | 2200 | 2500 | 2500 | 3000 | |
| Qhov siab (H) | 450 | 500 | 550 | 600 | 650 | 700 | 1200 | |
| Log Base (mm) | 1200 | 2600 | 2800 | 3200 | 4200 | 4300 | 7000 | |
| Log Dia (mm) | Φ270 | Φ300 | Φ350 | Φ400 | Φ500 | Φ600 | Φ600 | |
| Av Clearance (mm) | 50 | 50 | 50 | 50 | 50 | 75 | 75 | |
| Lub cev muaj zog (Kw) | 1 | 1.6 | 2.2 | 3.5 | 5 | 6.3 | 15 | |
| Roj teeb muaj peev xwm (Ah) | 180 | 160 | 180 | 250 | 330 | 400 | 600 | |
| Roj teeb Voltage (V) | 24 | 48 | 48 | 48 | 48 | 48 | 72 | |
| Lub Sijhawm Ua Haujlwm Thaum Ntxov Tag Nrho | 4.32 | 4.8 | 4 | 3.5 | 3.3 | 3 | 2.9 | |
| Kev khiav deb ntawm ib qho nqi (Km) | 6.5 | 7.2 | 4.8 | 4.2 | 4 | 3.6 | 3.2 | |
| Max Log Load (KN) | 14.4 | 42.6 | 77.7 | 110.4 | 174 | 221.4 | 265.2 | |
Daim ntawv thov
Cov khoom siv lossis cov khoom thauj khoom thauj - Kev hloov pauv hloov - Lub tank hloov pauv - Lub tshuab txav txav tau yooj yim
Nta
Pav ca steel lawj – Pav ca Tread Steel Log – Tsav Tsav – Voltage Meter – Push Button Pendant
Kev xaiv
Railings - AC fais fab - Cable reel - ceeb toom tswb - Ntoo decking khoom - Stainless hlau decking - Kev cai xim xim - Rail qhia - End nres
Cim npe nrov: 50 tons tshwj xeeb hloov lub laub on-rail, Tuam Tshoj, tuam ntxhab, lwm tus muag khoom, Hoobkas, kho, ua nyob rau hauv Suav teb
